Products specifications

Categories Uncategorized
Manufacturer Diptronics
Popularity Low
Supply and Demand Status Balance
Win Source Part Number 843267-DM-03-V
Ultra Librarian 3D Model Ultra Librarian DM-03-V CAD Model

Description

The DM-03-V is a miniature DIP switch manufactured by Diptronics. DIP switches are used to configure electronic devices by setting specific circuits on or off. They are commonly found on printed circuit boards (PCBs) and are used to set options such as device addresses, boot parameters, or other configurable settings.

Applications

  • Printed Circuit Boards (PCBs): Used for configuring various settings on PCBs.
  • Industrial Control Systems: Employed for setting parameters in industrial controllers.
  • Networking Equipment: Utilized for configuring network devices such as routers and switches.
  • Embedded Systems: Integrated into embedded systems for setting device options and configurations.
  • Consumer Electronics: Used in various consumer electronic devices for setting user-configurable options.

Features

  • Miniature Size: Compact design allows for use in space-constrained applications.
  • DIP Package: Standard DIP (Dual In-line Package) allows for easy mounting on PCBs.
  • Multiple Switch Positions: Offers multiple switches for various configuration options.
  • Reliable Contacts: Designed with reliable contacts for consistent performance.
  • Easy to Operate: Simple switch mechanism allows for easy setting and changing of configurations.

Benefits

  • Flexible Configuration: Provides a flexible way to configure electronic devices without the need for software changes.
  • Easy to Install: Simple DIP package allows for easy installation on PCBs.
  • Cost-Effective: Provides a cost-effective solution for setting device configurations.
  • Reliable Performance: Ensures consistent and dependable performance in various environments.
  • Space-Saving: Miniature size allows for use in space-constrained applications.

Additional Details

The DM-03-V DIP switch features a standard DIP package for easy installation on PCBs. The '03' in the name indicates that it has 3 switches. The 'V' likely refers to vertical orientation, meaning the switch actuators are oriented vertically when mounted on a PCB. It is designed to withstand typical environmental conditions encountered in electronic devices. For detailed specifications such as voltage and current ratings, operating temperature range, and contact resistance, consult the official product datasheet from Diptronics. These switches are particularly useful in applications where permanent or semi-permanent configuration settings are required and where frequent changes are not expected.
