A1635-2R5475-R
Same model may have multiple batches, images only for reference.

A1635-2R5475-R

Part No A1635-2R5475-R
Manufacturer Eaton Bussmann
Catalog Electric Double Layer Capacitors, Supercaps
Description CAP 4.7F -20% +80% 2.5V T/H / 4.7 F (EDLC) Supercapacitor 2.5 V Radial, Can 25mOhm @ 1kHz 1000 Hrs @ 70°C
Datasheet
A1635-2R5475-R Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Electric Double Layer Capacitors (EDLC), Supercapacitors
Mfr Eaton Bussmann
Series A
Package Bulk
Product Status Obsolete
Capacitance 4.7 F
Tolerance -20%, +80%
Voltage - Rated 2.5 V
ESR (Equivalent Series Resistance) 25mOhm @ 1kHz
Lifetime @ Temp. 1000 Hrs @ 70°C
Termination PC Pins
Mounting Type Through Hole
Package / Case Radial, Can
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.650" Dia (16.50mm)
Height - Seated (Max) 1.496" (38.00mm)
Temperature Range - Operating -25°C ~ 70°C
Standard Package 100 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8532.29.0040
Win Source Part Number 908877-A1635-2R5475-R
Ultra Librarian 3D Model Ultra Librarian A1635-2R5475-R CAD Model

Description

The A series electric double-layer capacitor is a high-capacity component designed for energy storage applications. Bold the product name (e.g., BAV99S,135 → Electric Double-Layer Capacitor) and manufacturer (e.g., Nexperia USA Inc. → Abracon LLC).

  • Series: A
  • Capacitance: 4.7F
  • Voltage Rating: 2.5V
  • Diameter: 0.650"
  • Height: 1.496"
  • Mounting Type: Through-Hole
  • ESR: 25mOhm @ 1kHz
  • Temperature Range: -25°C to 70°C
  • Lifetime: 1000 hours @ 70°C
  • Part Status: Obsolete
