ECS-147.4-20-3X-EN-TR Real Image
Same model may have multiple batches, images only for reference.

ECS-147.4-20-3X-EN-TR

Part No ECS-147.4-20-3X-EN-TR
Manufacturer ECS Inc.
Catalog Oscillators
Description CRYSTAL 14.7456MHZ 20PF SMD / 14.7456 MHz ±30ppm Crystal 20pF 60 Ohms HC-49/US
Datasheet
ECS-147.4-20-3X-EN-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr ECS Inc.
Series CSM-3X
Package Tape & Reel
Product Status Active
Type MHz Crystal
Frequency 14.7456 MHz
Frequency Stability ±50ppm
Frequency Tolerance ±30ppm
Load Capacitance 20pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case HC-49/US
Size / Dimension 0.276" L x 0.161" W (7.00mm x 4.10mm)
Height - Seated (Max) 0.091" (2.30mm)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 917793-ECS-147.4-20-3X-EN-TR
Ultra Librarian 3D Model Ultra Librarian ECS-147.4-20-3X-EN-TR CAD Model

Description

The CSM-3X series from ECS Inc. is a MHz crystal with a frequency of 14.7456 MHz.

  • Load Capacitance: 20pF
  • Mode: Fundamental
  • Mounting: Surface mountable
  • Package: HC-49/US
  • Temperature Range: -40°C to 85°C
  • ESR (Equivalent Series Resistance): 60 Ohms
  • Frequency Stability: ±50ppm
  • Frequency Tolerance: ±30ppm
  • Category: Crystals, Oscillators, Resonators
  • Market Status: Active
