B78108S1105J EPCOS (TDK)
Same model may have multiple batches, images only for reference.

B78108S1105J

Part No B78108S1105J
Manufacturer EPCOS (TDK)
Catalog Fixed Inductors
Description FIXED IND 1MH 130MA 14 OHM TH
Datasheet
B78108S1105J Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer EPCOS (TDK)
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 1mH
Tolerance ±5%
Current Rating 130mA
DC Resistance (DCR) 14 Ohm Max
Q @ Freq 50 @ 252kHz
Frequency - Self Resonant 1.6MHz
Temperature Range - Operating -55°C to 125°C
Frequency - Test 252kHz
Mounting Through Hole
Case / Package Axial
Dimension 0.157" Dia x 0.362" L (4.00mm x 9.20mm)
Win Source Part Number 097949-B78108S1105J
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian B78108S1105J CAD Model

Description

Product Overview

The B78108S1105J inductor is designed for applications requiring precise inductance values and superior performance. Its robust characteristics make it ideal for enhancing signal integrity and reducing noise in various circuits.

Features and Benefits

  • Precision Inductance: Provides consistent inductance values for optimal accuracy.
  • Temperature Stability: Maintains performance across a wide temperature range.
  • RoHS Compliant: Environmentally friendly with adherence to global safety standards.
  • Easy Integration: Compatible with a variety of PCB designs.

Applications

  • RF Circuits
  • Signal Processing
  • Switch Mode Power Supplies (SMPS)
  • LED Drivers

The B78108S1105J is tailored for professionals seeking high accuracy and reliability in demanding electronic systems.
