The M13S2561616A-5TIG2S is a 256Mb SDRAM (Synchronous Dynamic Random-Access Memory) chip manufactured by ESMT. This memory component is designed for applications where high memory capacity and fast data access are essential. It's commonly used in embedded systems, networking equipment, and various consumer electronic devices.

Applications:

• Embedded Systems
• Networking Devices (Routers, Switches)
• Consumer Electronics (Set-Top Boxes, Digital TVs)
• Industrial Control Systems
• Gaming Consoles

Features:

• Capacity: 256Mb (16Mb x 16)
• Organization: Configured as 16 Meg x 16 bits
• Interface: Standard SDRAM interface
• Clock Rate: Supports clock rates up to 133 MHz (based on -5 speed grade)
• Power Supply: Operates at standard SDRAM voltage (e.g., 3.3V)
• Refresh: Auto and Self Refresh modes
• Package: Available in various package options, including TSOP and BGA
• Temperature Range: Supports commercial and industrial temperature ranges

Benefits:

• High Performance: Enables rapid data access, improving overall system responsiveness.
• Low Power Consumption: Designed for energy efficiency, extending battery life in portable applications.
• Reliable Operation: Ensures stable and consistent performance across various operating conditions.
• Compact Size: Offered in compact packages for use in space-constrained environments.
• Cost-Effective: Provides an optimal balance of performance and cost.

Additional Details:

The M13S2561616A-5TIG2S utilizes a synchronous interface to facilitate high-speed data transfers. It supports burst read and write operations, enhancing data throughput. The integration of auto-refresh and self-refresh modes enables efficient power management and reliable data retention. For detailed timing specifications and electrical characteristics, refer to the official datasheet provided by ESMT. The '-5TIG2S' designation indicates specific attributes related to speed grade and packaging.
