ESP32-D0WDQ6-V3 Real Image ESP32-D0WDQ6-V3 real image24303
Same model may have multiple batches, images only for reference.
ESP32-D0WDQ6-V3 Real Image ESP32-D0WDQ6-V3 real image24303
ESP32-D0WDQ6-V3 Real Image ESP32-D0WDQ6-V3 real image24303
Same model may have multiple batches, images only for reference.

ESP32-D0WDQ6-V3

Part No ESP32-D0WDQ6-V3
Manufacturer Espressif
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU BLUETOOTH WIFI
Datasheet
ESP32-D0WDQ6-V3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Espressif
Series ESP32
Package Tape & Reel
Product Status Not For New Designs
Programmable Not Verified
Type TxRx + MCU
RF Family/Standard Bluetooth, WiFi
Protocol 802.11b/g/n, Bluetooth 4.2
Modulation 8DPSK, DSSS, DQPSK, OFDM
Frequency 2.412GHz ~ 2.484GHz
Data Rate (Max) 150Mbps
Power - Output 20.5dBm
Sensitivity -97dBm
Memory Size 448kB ROM, 520kB SRAM
Serial Interfaces ADC, I²C, I²S, SDIO, SPI, PWM, UART
GPIO 34
Voltage - Supply 2.3V ~ 3.6V
Current - Receiving 95mA ~ 100mA
Current - Transmitting 130mA ~ 240mA
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Supplier Device Package 48-QFN (6x6)
Base Product Number ESP32-D0
Standard Package 3,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8542.39.0001
Win Source Part Number 851977-ESP32-D0WDQ6-V3
Ultra Librarian 3D Model Ultra Librarian ESP32-D0WDQ6-V3 CAD Model

Description

The 851977-ESP32-D0WDQ6-V3 is an RF transceiver IC that also includes a microcontroller unit (MCU) from Espressif.

  • Series: ESP32
  • Frequency: 2.412GHz ~ 2.484GHz
  • Protocols: 802.11b/g/n, Bluetooth 4.2
  • Memory Size: 448kB ROM, 520kB SRAM
  • Function: RF Transceiver IC
  • Programmable: Yes
  • Power - Output: 20.5dBm
  • Sensitivity: -97dBm
  • Data Rate (Max): 150Mbps
  • Package: Tape & Reel (TR)
  • Standard Package: 3,000 pcs
  • ECCN: 5A992C
  • REACH: Not Affected
