9595494902

Part No 9595494902
Manufacturer FAIR-RITE PRODUCTS
Catalog Ferrite Cores
Description FERRITE CORE ETD 95 SET
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Type ETD
Material 95
Tolerance ±25%
Gap Ungapped
Initial Permeability (µi) 3000
Core Factor (ΣI/A) mm⁻¹ 53.0
Effective Length (le) mm 114.4
Effective Area (Ae) mm2 213.5
Minimum Core Cross Section (Amin) mm2 209.0
Effective Magnetic Volume (Ve) mm3 24420.0
Finish Uncoated
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1528170-9595494902
Ultra Librarian 3D Model Ultra Librarian 9595494902 CAD Model
