Same model may have multiple batches, images only for reference.

FDD306P

Name: FDD306P
Brand: Fairchild/ON Semiconductor
SKU: 453107
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	FDD306P
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH 12V 6.7A 3-Pin(2+Tab) DPAK T/R / MOSFET P-CH 12V 6.7A DPAK
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	12V
Continuous Drain Current at 25°C	6.7A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	1.8V, 4.5V
Gate-Source Threshold Voltage	1.5V @ 250μA
Max Gate Charge	21nC @ 4.5V
Max Input Capacitance	1290pF @ 6V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	52W (Ta)
Maximum Rds On at Id,Vgs	28 mOhm @ 6.7A, 4.5V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-252
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	1038058-FDD306P
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	2,500
Family Name	FDD306P
Introduction Date	January 06, 2005
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian FDD306P CAD Model

Alternative Products

Description

The FDD306P is a P-Channel MOSFET manufactured by Fairchild/ON Semiconductor.

Drain-Source Breakdown Voltage: 12V
Continuous Drain Current @ 25°C: 6.7A
Gate-Source Threshold Voltage: 1.5V @ 250μA
Maximum Gate Charge: 21nC @ 4.5V
Maximum Rds On @ Id,Vgs: 28 mOhm @ 6.7A, 4.5V
Choice: Popular
Application: Discrete semiconductor products
Features: Halogen-free
Compliance: ECCN
Estimated EOL date: 2027
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
