FDS6681Z

Name: FDS6681Z
Brand: Fairchild/ON Semiconductor
SKU: 129868
Availability: InStock
Rating: 4.85 (161 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDS6681Z
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 20A 8-SO
Datasheet	FDS6681Z Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	20A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	260nC @ 10V
Max Input Capacitance	7540pF @ 15V
Maximum Gate-Source Voltage	±25V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	4.6 mOhm @ 20A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	016166-FDS6681Z
Family Name	FDS6681
Introduction Date	June 29, 2005
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Power Management, Consumer Electronics
Quantity per package	2,500
Ultra Librarian 3D Model	Ultra Librarian FDS6681Z CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FDS6681Z is a P-channel MOSFET with a drain-source breakdown voltage of 30V. It has a power dissipation of 2.5W (Ta) and a continuous drain current of 20A (Ta).

Rds On (Max): 4.6 mOhm @ 20A, 10V
Drive Voltage: 4.5V, 10V (Max Rds On, Min Rds On)
Gate-Source Threshold Voltage: 3V @ 250μA
Mounting: SMD (SMT)
Packaging: Reel - TR
Supply and Demand Status: Limited
Applications: Power Management, Consumer Electronics
Package Quantity: 2,500
