Same model may have multiple batches, images only for reference.

FQP27P06

Name: FQP27P06
Brand: Fairchild/ON Semiconductor
SKU: 132579
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	FQP27P06
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 60V 27A TO-220
Datasheet	FQP27P06 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Tube/Rail
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	27A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	43nC @ 10V
Max Input Capacitance	1400pF @ 25V
Maximum Gate-Source Voltage	±25V
Power Dissipation (Max)	120W (Tc)
Maximum Rds On at Id,Vgs	70 mOhm @ 13.5A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	TO-220-3
Dimension	TO-220-3
Win Source Part Number	091894-FQP27P06
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Power Management, Consumer Electronics, Portable Devices, Industrial
Quantity per package	1k pcs
Ultra Librarian 3D Model	Ultra Librarian FQP27P06 CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FQP27P06 MOSFET is a P-Channel transistor designed for use in power management, consumer electronics, portable devices, and industrial applications.

Maximum Power Dissipation: 120W (Tc)
Drain-Source Breakdown Voltage: 60V
Continuous Drain Current: 27A (Tc)
Maximum Rds On: 70 mOhm @ 13.5A, 10V
Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Gate Charge: 43nC @ 10V
Maximum Input Capacitance: 1400pF @ 25V
Package: TO-220-3
Packaging: Tube/Rail
Supply and Demand: Limited
