HMA121F

Name: HMA121F
Brand: Fairchild/ON Semiconductor
SKU: 598374
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	HMA121F
Manufacturer	Fairchild/ON Semiconductor
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	FULL PITCH MINI-FLAT PACKAGE 4-PIN OPTOCOUPLERS
Datasheet	HMA121F Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Fairchild/ON Semiconductor
Packaging	Tube
Part Status	Obsolete(EOL)
Number of Channels	1
Voltage - Isolation	3750Vrms
Current Transfer Ratio (Minimum)	100% @ 5mA
Current Transfer Ratio (Maximum)	600% @ 5mA
Rise / Fall Time (Typ)	3μs, 3μs
Input Type	DC
Output Type	Transistor
Output Voltage MAX	80V
Output Current per Channel	80mA
Voltage - Forward (Vf) (Typ)	1.3V (Maximum)
Current - DC Forward (If) (Maximum)	50mA
Vce Saturation (Maximum)	400mV
Operating Temperature Range	-40°C ~ 100°C
Mounting	SMD
Package	4-SMD, Gull Wing
Manufacturer Package	4-Mini-Flat
Win Source Part Number	1181062-HMA121F
Manufacturer Homepage	www.fairchildsemi.com
Popularity	Medium
Supply and Demand Status	Balance
Family Name	HMA121
Introduction Date	April 10, 2002
ECCN	EAR99
Country of Origin	Thailand
Estimated EOL Date	Obsolete
Ultra Librarian 3D Model	Ultra Librarian HMA121F CAD Model

Description

The HMA121F is an obsolete (EOL) electronic component manufactured by Fairchild/ON Semiconductor.

Output: Single-channel optocoupler with transistor output
Package: 4-SMD, Gull Wing
Output Voltage (Max): 80V
Output Current per Channel: 80mA
Current Transfer Ratio: 100% @ 5mA (minimum), 600% @ 5mA (maximum)
Halogen-Free: Yes
Estimated EOL Date: Obsolete
Supply and Demand: Balanced
