ISL9R1560S3ST Fairchild/ON Semiconductor
ISL9R1560S3ST Fairchild/ON Semiconductor ISL9R1560S3ST Real Image1 ISL9R1560S3ST Real Image2
Same model may have multiple batches, images only for reference.

ISL9R1560S3ST

Part No ISL9R1560S3ST
Manufacturer Fairchild/ON Semiconductor
Catalog Electronic Surplus
Description 600 V Reverse Voltage and High Reliability
Datasheet
ISL9R1560S3ST Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Family Name ISL9R1560S3S
Introduction Date May 03, 2002
ECCN EAR99
Manufacturer Homepage www.fairchildsemi.com
Win Source Part Number 1190563-ISL9R1560S3ST
Operating Temperature - Junction -55°C ~ 175°C
Manufacturer Package TO-263 (D2Pak)
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting SMD
Current - Reverse Leakage @ Vr 100ÎĽA @ 600V
Reverse Recovery Time (trr) 40ns
Speed Fast Recovery = 200mA (Io)
Voltage - Forward (Vf) (Maximum) @ If 2.2V @ 15A
Current - Average Rectified (Io) 15A
Voltage - DC Reverse (Vr) (Maximum) 600V
Diode Type Standard
Packaging Reel - TR
Series Stealth
Manufacturer Fairchild/ON Semiconductor
Categories Discrete Semiconductor Products
Supply and Demand Status Balance
Popularity High
Is this a common-used part? Yes
Estimated EOL Date 2023
Halogen Free Compliant
Country of Origin China, Republic of Korea
Quantity per package 800
Win Source Part Number STTH12R06G-TR;  STTH12R06G;  VS-15ETX06STRLPbF;

Description

The Fairchild/ON Semiconductor Diode is a high-performance solution for electronic applications. The product has a balance supply and demand status and is part of the Discrete Semiconductor Products category. It has a Win Source Part Number of 1190563-ISL9R1560S3ST and is available in reel - TR packaging with a quantity per package of 800. The diode has a current - average rectified (Io) of 15A and a reverse recovery time (trr) of 40ns. It has a voltage - forward (Vf) (maximum) @ If of 2.2V @ 15A and a voltage - DC reverse (Vr) (maximum) of 600V. The diode operates in a temperature range of -55°C to 175°C and is manufactured by Fairchild/ON Semiconductor.
