KA3525A Real Image KA3525A real image627
Same model may have multiple batches, images only for reference.
KA3525A Real Image KA3525A real image627
KA3525A Real Image KA3525A real image627
Same model may have multiple batches, images only for reference.

KA3525A

Part No KA3525A
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR 16DIP
Datasheet
KA3525A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Transistor Driver
Number of Outputs 2
Output Phases 1
Supply Voltage - Operating 7 V to 20 V
Frequency - Switching 60Hz to 430kHz
Duty Cycle (Max) 49%
Synchronous Rectifier Yes
Clock Sync Yes
Control Features Enable, Soft Start
Temperature Range - Operating 0°C to 70°C (TA)
Case / Package 16-DIP
Win Source Part Number 070380-KA3525A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Consumer Electronics
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian KA3525A CAD Model

Description

The KA3525A is an integrated circuit manufactured by Fairchild/ON Semiconductor.

  • Supply and Demand Status: Balanced
  • Output Type: Transistor driver
  • Synchronous Rectifier: Yes
