KSA1156OSTU Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

KSA1156OSTU

Part No KSA1156OSTU
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS PNP 400V 0.5A TO-126 / Trans GP BJT PNP 400V 0.5A 1000mW 3-Pin(3+Tab) TO-126 Tube
Datasheet
KSA1156OSTU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Part Status Obsolete(EOL)
Transistor Type PNP
Current - Collector (Ic) (Maximum) 500mA
Voltage - Collector Emitter Breakdown (Maximum) 400V
Vce Saturation (Maximum) @ Ib, Ic 1V @ 10mA, 100mA
Current - Collector Cutoff (Maximum) 100μA (ICBO)
DC Current Gain (hFE) (Minimum) @ Ic, Vce 60 @ 100mA, 5V
Power - Max 1W
Operating Temperature Range 150°C (TJ)
Mounting Style Through Hole
Package TO-225AA, TO-126-3
Manufacturer Package TO-126-3
Win Source Part Number 778028-KSA1156OSTU
Popularity Medium
Supply and Demand Status Limited
Quantity per package 60
Family Name KSA1156O
Introduction Date November 14, 2000
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian KSA1156OSTU CAD Model

Description

The KSA1156OSTU is a PNP transistor from the KSA1156O family name of Fairchild/ON Semiconductor.

  • Package: TO-225AA, TO-126-3
  • Mounting: Through-hole
  • Maximum Power: 1W
  • Maximum Collector Current: 500mA
  • Voltage Collector Emitter Breakdown: 400V
  • Vce saturation: 1V @ 10mA, 100mA
  • Maximum Collector Cutoff: 100μA (ICBO)
  • DC Current Gain: 60 @ 100mA, 5V
  • Status: Obsolete
  • ECCN: EAR99
  • HTSUS: 8541.29.0075
  • Packaging: Tube, 60 units
