KSC5502DTM Real Image KSC5502DTM Real Image
Same model may have multiple batches, images only for reference.
KSC5502DTM Real Image KSC5502DTM Real Image
KSC5502DTM Real Image KSC5502DTM Real Image
Same model may have multiple batches, images only for reference.

KSC5502DTM

Part No KSC5502DTM
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description High Voltage Power Switch Switching Application
Datasheet
KSC5502DTM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Transistor Type NPN
Current - Collector (Ic) (Maximum) 2A
Voltage - Collector Emitter Breakdown (Maximum) 600V
Vce Saturation (Maximum) @ Ib, Ic 1.5V @ 200mA, 1A
Current - Collector Cutoff (Maximum) 100μA
DC Current Gain (hFE) (Minimum) @ Ic, Vce 4 @ 1A, 1V
Power - Max 50W
Frequency - Transition 11MHz
Operating Temperature Range 150°C (TJ)
Mounting SMD
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Package TO-252AA
Win Source Part Number 1193605-KSC5502DTM
Manufacturer Homepage www.fairchildsemi.com
Family Name KSC5502D
Introduction Date November 14, 2000
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian KSC5502DTM CAD Model

Description

The KSC5502DTM is a NPN transistor from Fairchild/ON Semiconductor that is designed for use in discrete semiconductor products.

  • Power: 50W
  • Frequency Transition: 11MHz
  • Package: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Mounting Type: SMD
  • Collector Current: 2A
  • Collector Emitter Breakdown Voltage: 600V
  • Vce Saturation: 1.5V @ 200mA, 1A
  • Collector Cutoff: 100μA
  • DC Current Gain (hFE): 4 @ 1A, 1V
  • Introduction Date: November 14, 2000
  • Compliance: ECCN and Halogen-Free
  • Estimated EOL Date: 2023
  • Supply and Demand: Balance
  • Package Quantity: 2,500 units
