LM317LZ Fairchild/ON Semiconductor LM317LZ Real Image LM317LZ real image 2 LM317LZ label picture LM317LZ label picture 2 LM317LZ label picture 3
Same model may have multiple batches, images only for reference.
LM317LZ Fairchild/ON Semiconductor LM317LZ Real Image LM317LZ real image 2 LM317LZ label picture LM317LZ label picture 2 LM317LZ label picture 3
LM317LZ Fairchild/ON Semiconductor LM317LZ Real Image LM317LZ real image 2 LM317LZ label picture LM317LZ label picture 2 LM317LZ label picture 3
Same model may have multiple batches, images only for reference.

LM317LZ

Part No LM317LZ
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description Standard Regulator Pos 1.2V to 37V 0.05A 3-Pin TO-92 Bag / IC REG LINEAR ADJ 0.1A TO92-3
Datasheet
LM317LZ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 40V
Nominal Output Voltage (Min/Fixed) 1.2V
Maximum Output Voltage 37V
Output Current 100mA
PSRR 80dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.2 V to 37 V
Mounting Through Hole
Case / Package TO-92-3
Win Source Part Number 019040-LM317LZ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management
Family Name LM317L
Introduction Date January 15, 1997
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LM317LZ CAD Model

Description

The Fairchild/ON Semiconductor 019040-LM317LZ is a positive adjustable regulator with a single regulator topology and an output type that is adjustable.

  • Output Voltage: 1.2 V to 37 V
  • Maximum Input Voltage: 40V
  • Output Current: 100mA
  • Dropout Voltage: Max
  • Package: TO-92-3 case
  • Market Status: Active
  • Supply and Demand: Sufficient
  • Applications: Power management applications
  • Protection Features: Over-temperature and short-circuit protection
