LP2951CMX Real Image LP2951CMX real image1878 LP2951CMX Real Image
Same model may have multiple batches, images only for reference.
LP2951CMX Real Image LP2951CMX real image1878 LP2951CMX Real Image
LP2951CMX Real Image LP2951CMX real image1878 LP2951CMX Real Image
Same model may have multiple batches, images only for reference.

LP2951CMX

Part No LP2951CMX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 1.26V to 28V 0.1A Automotive 8-Pin SOIC T/R / IC REG LDO ADJ 0.1A 8SOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Output Type Adjustable (Fixed)
Number of Regulators 1
Maximum Input Voltage 30V
Nominal Output Voltage (Min/Fixed) 1.26V (5V)
Maximum Output Voltage 29.4V
Dropout Voltage-Max 0.6V @ 100mA
Output Current 100mA
Operating Supply Current 140μA to 7mA
Control Features Enable
Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.26 V to 28 V
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 019757-LP2951CMX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing, Imaging, Video & Vision, Audio, Portable Devices, Communications & Networking, Medical
Quantity per package 3k pcs
Family Name LP2951
Introduction Date May 19, 2001
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2021
Ultra Librarian 3D Model Ultra Librarian LP2951CMX CAD Model

Description

The LP2951CMX/NOPB is a versatile, high-performance voltage regulator from Texas Instruments. It is designed to provide a regulated output voltage from 2.5V to 30V with an adjustable output voltage range of 1.24V to 29V.

  • Input Voltage Range: 2.5V - 30V
  • Output Voltage Range: 1.24V to 29V
  • Maximum Output Current: 100mA
  • Low Dropout Voltage: Ensures efficient operation even with low input-output differential
  • Protection Features: Thermal shutdown, current limiting, and error flag output for low output voltage
  • Quiescent Current: 75μA at 100µA load, 1µA in shutdown mode
  • Operating Temperature Range: -40°C to +125°C
  • Package: 8-pin SOIC
