MBR0520L

Name: MBR0520L
Brand: Fairchild/ON Semiconductor
SKU: 220548
Availability: InStock
Rating: 4.93 (199 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MBR0520L
Manufacturer	Fairchild/ON Semiconductor
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 20V 500MA SOD123
Datasheet	MBR0520L Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	20V
Current - Average Rectified (Io)	500mA
Voltage - Forward (Vf) (Max) @ If	385mV @ 500mA
Speed(Frequency)	Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr	250μA @ 20V
Mounting	SMD (SMT)
Case / Package	SOD-123
Operating Temperature - Junction	-65°C to 125°C
Win Source Part Number	074267-MBR0520L
Popularity	Medium
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian MBR0520L CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor electronic component is a Schottky diode with a maximum DC reverse voltage of 20V and an average rectified current of 500mA.

Manufacturer: Fairchild/ON Semiconductor
Type: Schottky diode
Maximum DC Reverse Voltage: 20V
Average Rectified Current: 500mA
Forward Voltage: 385mV @ 500mA
Reverse Leakage Current: 250μA @ 20V
Recovery Speed: 200mA
Case/Package: SOD-123
Product Category: Discrete semiconductor product
Status: Active
Win Source Part Number: 074267-MBR0520L
