MMSZ5246B Real Image MMSZ5246B real image3519
Same model may have multiple batches, images only for reference.
MMSZ5246B Real Image MMSZ5246B real image3519
MMSZ5246B Real Image MMSZ5246B real image3519
Same model may have multiple batches, images only for reference.

MMSZ5246B

Part No MMSZ5246B
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes - Zener - Single
Description DIODE ZENER 16V 500MW SOD123
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Fairchild Semiconductor
Standard Package 1
Category Discrete Semiconductor Products
Family Diodes - Zener - Single
Packaging Reel
Voltage - Zener (Nom) (Vz) 16V
Tolerance ±5%
Power - Max 500mW
Impedance (Max) (Zzt) 17 Ohm
Current - Reverse Leakage @ Vr 100nA @ 12V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Operating Temperature Range -55°C ~ 150°C
Mounting Style SMD/SMT
Package SOD-123
Manufacturer Device Package SOD-123
Catalog MMSZ Zener Diode
Win Source Part Number 059245-MMSZ5246B
Popularity Medium
Supply and Demand Status Balance
Package Tape & Reel (TR)
Product Status Active
Impedance (Max) (Zzt) 17 Ohms
Current - Reverse Leakage @ Vr 100nA @ 14V
Operating Temperature -65°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Ultra Librarian 3D Model Ultra Librarian MMSZ5246B CAD Model

Description

The Fairchild Semiconductor diode with a Win Source Part Number of 059245-MMSZ5246B is a reliable and efficient choice for discrete semiconductor products.

  • Package: SOD-123
  • Manufacturer Device Package: SOD-123
  • Tolerance: ±5%
  • Maximum Power: 500mW
  • Maximum Impedance: 17 Ohm
  • Supply and Demand Status: Balanced
  • Operating Temperature Range: -55°C ~ 150°C
