NC7S08P5X Real Image NC7S08P5X real image3854 NC7S08P5X real image3855 NC7S08P5X Real Image
Same model may have multiple batches, images only for reference.
NC7S08P5X Real Image NC7S08P5X real image3854 NC7S08P5X real image3855 NC7S08P5X Real Image
NC7S08P5X Real Image NC7S08P5X real image3854 NC7S08P5X real image3855 NC7S08P5X Real Image
Same model may have multiple batches, images only for reference.

NC7S08P5X

Part No NC7S08P5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE AND 1CH 2-INP SC-70-5
Datasheet
NC7S08P5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 2.6mA, 2.6mA
Logic Level - Low 0.5V
Logic Level - High 1.5V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 024731-NC7S08P5X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7S08P5X CAD Model

Description

The Fairchild/ON Semiconductor 024731-NC7S08P5X is an integrated circuit that is designed to function as an AND gate.

  • Popularity: High
  • Maximum Propagation Delay: 17ns @ 6V and 50pF
  • Current-Quiescent: 1μA
  • Package: SC-70-5
  • Supply Voltage: 2V to 6V
