NC7WZ08K8X Real Image NC7WZ08K8X real image3918 NC7WZ08K8X Real Image1 NC7WZ08K8X Real Image2 NC7WZ08K8X Real Image3 NC7WZ08K8X Real Image4
NC7WZ08K8X Real Image NC7WZ08K8X real image3918 NC7WZ08K8X Real Image1 NC7WZ08K8X Real Image2 NC7WZ08K8X Real Image3 NC7WZ08K8X Real Image4
Same model may have multiple batches, images only for reference.

NC7WZ08K8X

Part No NC7WZ08K8X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE AND 2CH 2-INP US8
Datasheet
NC7WZ08K8X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 2
Number of Inputs 2
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 32mA, 32mA
Max Propagation Delay @ V, Max CL 3.7ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package US8
Dimension 8-VFSOP (0.091", 2.30mm Width)
Win Source Part Number 024868-NC7WZ08K8X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7WZ08K8X CAD Model

Description

The Fairchild/ON Semiconductor NC7WZ08K8X is an AND gate logic type with two inputs and two circuits.

  • Mounting: SMD (SMT)
  • Category: Integrated circuit
  • Current Output (High/Low): 32mA
  • Maximum Propagation Delay: 3.7ns @ 5V, 50pF
  • Operating Temperature: -40°C to 85°C
  • Supply Voltage: 1.65 V to 5.5 V
  • Package: US8 (8-VFSOP (0.091", 2.30mm Width))
  • Supply and Demand Status: Balanced
  • Quantity: 3k pcs
  • Application: Industrial
