NC7WZ132K8X

Name: NC7WZ132K8X
Brand: Fairchild/ON Semiconductor
SKU: 250196
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

Part No	NC7WZ132K8X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	NAND Gate 2-Element 2-IN CMOS 8-Pin US T/R / IC GATE NAND 2CH 2-INP US8
Datasheet	NC7WZ132K8X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	NAND Gate
Number of Circuits	2
Number of Inputs	2
Features	Schmitt Trigger
Supply Voltage - Operating	1.65 V to 5.5 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	32mA, 32mA
Logic Level - Low	0.2 V to 1.2 V
Logic Level - High	1.4 V to 3.6 V
Max Propagation Delay @ V, Max CL	4.5ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	US8
Dimension	8-VFSOP (0.091", 2.30mm Width)
Win Source Part Number	024872-NC7WZ132K8X
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial
Quantity per package	3k pcs
Family Name	NC7WZ132
Introduction Date	December 09, 1998
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian NC7WZ132K8X CAD Model

Description

The Fairchild/ON Semiconductor NC7WZ132K8X is a NAND gate that has two circuits.

Feature: Schmitt trigger
Supply Voltage: 1.65 V to 5.5 V
Maximum Propagation Delay: 4.5ns @ 5V, 50pF
Current - Quiescent (Max): 1μA
Package: US8
Operating Temperature: -40°C to 85°C
Supply and Demand Status: Sufficient
Quantity: 3k pcs
