NC7WZ14EP6X

Part No NC7WZ14EP6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC INVERTER UHS SCHMITT SC70-6
Datasheet
NC7WZ14EP6X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 2
Number of Inputs 2
Features Schmitt Trigger
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 32mA, 32mA
Logic Level - Low 0.2 V to 1.2 V
Logic Level - High 1.4 V to 3.6 V
Max Propagation Delay @ V, Max CL 4.9ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-6
Dimension 6-TSSOP, SC-88, SOT-363
Win Source Part Number 024873-NC7WZ14EP6X
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7WZ14EP6X CAD Model

Description

The Fairchild/ON Semiconductor NC7WZ14EP6X is a 2-circuit inverter logic type IC with a Schmitt trigger feature.

  • Maximum Propagation Delay: 4.9ns @ 5V and 50pF
  • Quiescent Current: 1μA
  • Logic Level (Low): 0.2 V to 1.2 V
  • Logic Level (High): 1.4 V to 3.6 V
  • Package: SC-70-6
  • Mounting: Surface mount
  • Status: Active
  • Popularity: Medium
  • Supply and Demand Status: Balanced
  • Quantity: 3,000 pieces
