PZT3904 Real Image PZT3904 real image4979
Same model may have multiple batches, images only for reference.
PZT3904 Real Image PZT3904 real image4979
PZT3904 Real Image PZT3904 real image4979
Same model may have multiple batches, images only for reference.

PZT3904

Part No PZT3904
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 40V 0.2A SOT223 / Trans GP BJT NPN 40V 0.2A 1000mW 4-Pin(3+Tab) SOT-223 T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 200mA
VCEO Maximum Collector-Emitter Breakdown Voltage 40V
Max Vce (sat) 300mV @ 5mA, 50mA
Typical Gain (hFE) (Min) 100 @ 10mA, 1V
Maximum Power Dissipation 1W
Frequency - Transition 300MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 096408-PZT3904
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Quantity per package 4k pcs
Family Name PZT3904
Introduction Date March 08, 2006
ECCN EAR99
Country of Origin Japan
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PZT3904 CAD Model

Description

The Fairchild/ON Semiconductor 096408-PZT3904 is an NPN transistor with a collector-emitter breakdown voltage of 40V and a maximum current collector of 200mA.

  • Case/Package: SOT-223-4
  • Temperature Range: -55°C to 150°C (TJ)
  • Frequency Transition: 300MHz
  • Maximum Power Dissipation: 1W
  • Description: The 096408-PZT3904 is a common choice for many discrete semiconductor products and has a high popularity in the market.
  • Compliance: Halogen-free compliant
  • Alternative Cross-Reference: PZT3904-T&R, PZT3904 E6327, and PZT3904 E6359
  • Application: Widely used in various industrial applications.
