The SMBJ18CA is a Transient Voltage Suppressor (TVS) diode manufactured by Fairchild/ON Semiconductor. It's designed to protect sensitive electronic components from voltage transients induced by lightning, inductive load switching, and electrostatic discharge (ESD). This device is part of the SMBJ series, known for its compact size and high surge capability.

Applications:

• I/O Port Protection
• VCC Bus Protection
• Data Line Protection
• Microprocessor Protection
• Protection of sensitive circuits against ESD and EFT

Features:

• Bidirectional TVS Diode
• Surface Mount SMB package
• Low profile
• Excellent clamping capability
• High surge capability: 600 W peak pulse power (tp = 10/1000 μs)
• Low incremental surge resistance
• Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C

Benefits:

• Effective protection against transient overvoltages, ensuring system reliability.
• Reduces component failure rates and associated maintenance costs.
• Compact size allows for use in densely populated circuit boards.
• Fast response time to transient events.
• Compliant with industry standards for surge protection.

Additional Details:

The SMBJ18CA features a standoff voltage of 18V and a breakdown voltage typically between 20V and 22.1V. The “CA” suffix indicates a bidirectional TVS diode. Bidirectional TVS diodes are used in applications where the polarity of the transient voltage is unknown or can be either positive or negative. The SMBJ18CA is available in a SMB (DO-214AA) package. Operating temperature ranges from -65°C to +150°C. This TVS diode is designed to clamp transient voltages to a safe level, protecting downstream components. Fairchild/ON Semiconductor's SMBJ18CA is engineered to provide robust protection in various applications where transient voltage surges are a concern.
