Same model may have multiple batches, images only for reference.

TIP42C

Name: TIP42C
Brand: Fairchild/ON Semiconductor
SKU: 366099
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	TIP42C
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors (BJT) - Single
Description	TRANS PNP 100V 6A TO220AB
Datasheet	TIP42C Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	ON Semiconductor
Packaging	Tube/Rail
Status	Active
Transistor Polarity	PNP
Maximum Current Collector	6A
VCEO Maximum Collector-Emitter Breakdown Voltage	100V
Max Vce (sat)	1.5V @ 600mA, 6A
Collector Cut-off Current(Max)	700μA
Typical Gain (hFE) (Min)	15 @ 3A, 4V
Maximum Power Dissipation	2W
Frequency - Transition	3MHz
Temperature Range - Operating	-65°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-220AB
Win Source Part Number	032189-TIP42C
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Communications & Networking, Audio, Signal Processing, Power Management
Package	Tube
Product Status	Active
Transistor Type	PNP
Current - Collector (Ic) (Max)	6A
Voltage - Collector Emitter Breakdown (Max)	100V
Vce Saturation (Max) @ Ib, Ic	1.5V @ 600mA, 6A
Current - Collector Cutoff (Max)	700µA
DC Current Gain (hFE) (Min) @ Ic, Vce	15 @ 3A, 4V
Power - Max	65W
Operating Temperature	150°C (TJ)
Grade	-
Mounting Type	Through Hole
Package / Case	TO-220-3
Supplier Device Package	TO-220
Ultra Librarian 3D Model	Ultra Librarian TIP42C CAD Model

Alternative Products

Description

The ON Semiconductor TIP42C is a PNP transistor with a maximum collector current of 6A and a collector-emitter breakdown voltage of 100V.

Maximum collector current: 6A
Collector-emitter breakdown voltage: 100V
Typical gain (hFE) (Min): 15 @ 3A, 4V
Maximum power dissipation: 2W
Operating temperature range: -65°C to 150°C (TJ)
