MC9RS08KA8CTG Real Image MC9RS08KA8CTG Real Image1 MC9RS08KA8CTG Real Image2 MC9RS08KA8CTG Real Image3 MC9RS08KA8CTG Real Image4
Same model may have multiple batches, images only for reference.
MC9RS08KA8CTG Real Image MC9RS08KA8CTG Real Image1 MC9RS08KA8CTG Real Image2 MC9RS08KA8CTG Real Image3 MC9RS08KA8CTG Real Image4
MC9RS08KA8CTG Real Image MC9RS08KA8CTG Real Image1 MC9RS08KA8CTG Real Image2 MC9RS08KA8CTG Real Image3 MC9RS08KA8CTG Real Image4
Same model may have multiple batches, images only for reference.

MC9RS08KA8CTG

Part No MC9RS08KA8CTG
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 8KB FLASH 16TSSOP
Datasheet
MC9RS08KA8CTG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube/Rail
Status Active
Core Processor RS08
Part Core Size 8-Bit
Speed(Frequency) 20MHz
Number of I/O 14
Program Memory Size 8KB (8K x 8)
Program Memory Type FLASH
Data RAM Size 254 x 8
Supply Voltage - Operating 1.8 V to 5.5 V
Data Converters A/D 12x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-TSSOP
Win Source Part Number 208076-MC9RS08KA8CTG
Ultra Librarian 3D Model Ultra Librarian MC9RS08KA8CTG CAD Model

Description

The NXP MC9RS08KA8CTG is an RS08 core processor with 8KB (8K x 8) of program memory size and a program memory type of FLASH.

  • I/Os: 14
  • Speed: 20MHz
  • Package/Case: 16-TSSOP
  • Status: Active
  • Temperature Range: -40°C to 85°C (TA)
  • Supply Voltage: 1.8V to 5.5V
  • Core Size: 8-bit
  • Data RAM Size: 254 x 8
  • Data Converters: A/D 12x10b
