Same model may have multiple batches, images only for reference.
MPX12D Real Image
Same model may have multiple batches, images only for reference.

MPX12D

Part No MPX12D
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR DIFF PRESS 1.45PSI MAX
Datasheet
MPX12D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Differential
Operating Pressure 1.45 PSI (10 kPa)
Output Type Wheatstone Bridge
Output 0 mV to 55 mV (3V)
Accuracy ±5%
Supply Voltage - Operating 3 V to 6 V
Port Style No Port
Termination Style PCB
Maximum Pressure 10.88 PSI (75 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 120346-MPX12D
Ultra Librarian 3D Model Ultra Librarian MPX12D CAD Model

Description

The NXP MPX12D is a differential pressure sensor with a Wheatstone Bridge output type.

  • Operating Pressure: 1.45 PSI
  • Maximum Pressure: 10.88 PSI
  • Output: 0 mV to 55 mV @ 3V
  • Accuracy: ±5%
  • Temperature Range: -40°C to 125°C
  • Supply Voltage: 3V to 6V
  • Suitable for: use in sensors and transducers
  • Termination Style: PCB
