MPX2200DP Real Image MPX2200DP Real Image
Same model may have multiple batches, images only for reference.
MPX2200DP Real Image MPX2200DP Real Image
MPX2200DP Real Image MPX2200DP Real Image
Same model may have multiple batches, images only for reference.

MPX2200DP

Part No MPX2200DP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR DIFF PRESS 29PSI MAX
Datasheet
MPX2200DP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Differential
Operating Pressure 29.01 PSI (200 kPa)
Output Type Wheatstone Bridge
Output 0 mV to 40 mV (10V)
Accuracy ±0.25%
Supply Voltage - Operating 10 V to 16 V
Port Size Male - 0.19" (4.93mm) Tube, Dual
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 116.03 PSI (800 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 085878-MPX2200DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Robotics, Sensing & Instrumentation, Medical, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian MPX2200DP CAD Model

Description

The NXP MPX2200DP is a high popularity electronic component that is commonly used in motor drive and control, robotics, sensing and instrumentation, medical, and test and measurement applications.

  • Feature: designed to be temperature compensated
  • Pressure Type: differential
  • Maximum Pressure: 116.03 PSI
  • Supply Voltage: 10V to 16V
  • Temperature Range: -40°C to 125°C
