KBJ4005G GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

KBJ4005G

Part No KBJ4005G
Manufacturer GeneSiC Semiconductor
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 50V 4A KBJ / 4 AMP GLASS PASSIVATED SILICON BRIDGE RECTIFIER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 50V
Current - Average Rectified (Io) 4A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 4A
Current - Reverse Leakage at Vr 5μA at 50V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, KBJ
Supplier Device Package KBJ
Manufacturer Pack Quantity 250
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809055-KBJ4005G
Ultra Librarian 3D Model Ultra Librarian KBJ4005G CAD Model

Description

The KBJ4005G is a single-phase diode manufactured by GeneSiC Semiconductor.

  • Average Rectified Current: 4A
  • Peak Reverse Voltage: 50V
  • Package: 4-SIP, KBJ
  • Operating Temperature Range: -55°C to 150°C
  • Forward Voltage @ Current: 1.1V @ 4A
  • Supply and Demand: Limited
  • Manufacturer Pack Quantity: 250
