Same model may have multiple batches, images only for reference.

1002

Name: 1002
Brand: Goford Semiconductor
SKU: 538206
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	1002
Manufacturer	Goford Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	N100V,RD(MAX)<250M@10V,RD(MAX)<2
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Goford Semiconductor
Package	Tape & Reel
Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	100 V
Current - Continuous Drain (Id) @ 25°C	2A
Rds On (Max) @ Id, Vgs	250mOhm @ 2A, 10V
Vgs(th) (Max) @ Id	3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	10 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	387 pF @ 10 V
Power Dissipation (Max)	1.3W
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	SOT-23
Package / Case	TO-236-3, SC-59, SOT-23-3
Standard Package	3,000 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	538206-1002
Ultra Librarian 3D Model	Ultra Librarian 1002 CAD Model

Alternative Products

Description

The 538206-1002 is an N-Channel MOSFET transistor from Goford Semiconductor.

Drain to Source Voltage: 100V
Continuous Drain Current: 2A @ 25°C
Rds On: 250mOhm @ 2A and 10V
Gate-Source Threshold Voltage: 3V @ 250µA
Maximum Power Dissipation: 1.3W
Package: TO-236-3, SC-59, SOT-23-3
Gate Charge: 10nC @ 10V
Input Capacitance: 387pF @ 10V
Maximum Vgs: ±20V
Operating Temperature Range: -55°C to 150°C
MSL Level: 3 (168 hours)
REACH Status: unaffected
HTSUS Code: 8541.29.0095
