76HPSB04GWRT

Name: 76HPSB04GWRT
Brand: Grayhill Inc.
SKU: 550972
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	76HPSB04GWRT
Manufacturer	Grayhill Inc.
Catalog	DIP Switches
Description	Surface Mount DIP Switches \| SWITCH PIANO DIP SPST 150MA 30V
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Switches
Manufacturer	Grayhill Inc.
Packaging	Reel
Circuit	SPST
Number of Positions	4
Current Rating (Amps)	150mA
Voltage Rating	30VDC
Actuator Type	Piano
Actuator Level	Raised
Contact Material	Copper Alloy
Contact Finish	Gold
Height Above Board	0.337" (8.56mm)
Mounting Style	SMT, Right Angle
Termination Style	Gull Wing
Pitch	0.100" (2.54mm), Full
Washable	No
Temperature Range - Operating	-40°C ~ 85°C
Body Material	Thermoplastic
Length	0.480" (12.19mm)
Mechanical Life	2,000 Cycles
Electrical Life	2,000 Cycles
Manufacturer Pack Quantity	1
MSL Level	1 (Unlimited)
Win Source Part Number	1133660-76HPSB04GWRT
Manufacturer Homepage	www.grayhill.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian 76HPSB04GWRT CAD Model

Alternative Products

Description

The Grayhill Inc. 1133660-76HPSB04GWRT is a 4-position SPST piano switch. It has a pitch of 0.100" (2.54mm) and full termination style gull wing.

Pitch: 0.100" (2.54mm)
Termination Style: Gull Wing
Contact Finish: Gold
Contact Material: Copper Alloy
Voltage Rating: 30VDC
Height Above Board: 0.337" (8.56mm)
Material: Thermoplastic
Mechanical Life: 2,000 Cycles
Mounting Type: Surface Mount Technology (SMT)
Switch Type: Right Angle
Actuator Level: Raised
Washable: No
Operating Temperature: -40°C to 85°C
Manufacturer Pack Quantity: 1
MSL Level: 1 (Unlimited)
Current Rating (Amps): 150mA
