Same model may have multiple batches, images only for reference.

78M08S

Name: 78M08S
Brand: Grayhill Inc.
SKU: 551038
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	78M08S
Manufacturer	Grayhill Inc.
Catalog	DIP Switches
Description	Thru-Hole DIP Switches \| SWITCH SLIDE DIP SPST 150MA 30V
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Switches
Manufacturer	Grayhill Inc.
Packaging	Tube
Status	Obsolete
Circuit	SPST
Number of Positions	8
Current Rating (Amps)	150mA
Voltage Rating	30VDC
Actuator Type	Slide (Standard)
Actuator Level	Raised
Contact Material	Copper Alloy
Contact Finish	Gold
Height Above Board	0.315" (8.00mm)
Mounting Style	Through Hole
Termination Style	PC Pin
Pitch	0.100" (2.54mm), Full
Washable	Yes
Features	Tape Seal
Temperature Range - Operating	-40°C ~ 85°C
Body Material	Thermoplastic
Length	0.880" (22.35mm)
Mechanical Life	2,000 Cycles
Electrical Life	2,000 Cycles
Manufacturer Pack Quantity	108
MSL Level	1 (Unlimited)
Win Source Part Number	1133726-78M08S
Manufacturer Homepage	www.grayhill.com
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian 78M08S CAD Model

Alternative Products

Description

The Grayhill Inc. 1133726-78M08S is a through-hole SPST circuit slide switch with 8 positions, 2.54mm pitch, and a tape seal feature. 1133726-78M08S is manufactured by Grayhill Inc..

Circuit: SPST
Positions: 8
Pitch: 2.54mm
Contact Material: Copper alloy with a gold finish
Voltage Rating: 30VDC
Actuator Level: Raised
Washable: Yes
Mechanical and Electrical Life: 2,000 cycles
Height Above Board: 8.00mm
Length: 22.35mm
Body Material: Thermoplastic
Temperature Range: -40°C ~ 85°C
Status: Obsolete
Popularity: Medium
Manufacturer Pack Quantity: 108
Current Rating: 150mA
