M20-9980545

Name: M20-9980545
Brand: Harwin Inc.
SKU: 627272
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	M20-9980545
Manufacturer	Harwin Inc.
Catalog	Rectangular Connectors
Description	Male Vertical Double Row PC Tail \| CONN HEADER VERT 10POS 2.54MM
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Harwin Inc.
Packaging	Bulk
Connector Type	Header, Cuttable
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	10
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Number of Positions Loaded	All
Style	Board to Board or Cable
Shrouding	Unshrouded
Mounting Style	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.240" (6.10mm)
Contact Length - Post	0.118" (3.00mm)
Overall Contact Length	0.460" (11.68mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Gold
Contact Material	Brass
Insulation Material	Polyamide (PA6T), Nylon 6T
Temperature Range - Operating	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	3A per Contact
Mated Stacking Heights	9.94mm, 10.64mm, 11.04mm, 16.54mm
Manufacturer Pack Quantity	500
MSL Level	1 (Unlimited)
Win Source Part Number	1209960-M20-9980545
Manufacturer Homepage	www.harwin.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian M20-9980545 CAD Model

Alternative Products

Description

The M20-9980545 is a male pin header, cuttable connector manufactured by Harwin Inc.

Supply and Demand Status: limited
Positions: 10
Mounting Style: through hole
Connector: unshrouded
Pitch-Mating: 0.100" (2.54mm)
Contact Finish-Mating: gold
Contact Length-Mating: 0.240" (6.10mm)
Win Source Part Number: 1209960-M20-9980545
