DF1B-18DP-2.5DS(01) Real Image
Same model may have multiple batches, images only for reference.

DF1B-18DP-2.5DS(01)

Part No DF1B-18DP-2.5DS(01)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 18POS 2.5MM / Connector Header Through Hole, Right Angle 18 position 0.098" (2.50mm)
Datasheet
DF1B-18DP-2.5DS(01) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series DF1B
Package Tray
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.098" (2.50mm)
Number of Positions 18
Number of Rows 2
Row Spacing - Mating 0.098" (2.50mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.177" (4.50mm)
Contact Length - Post 0.130" (3.30mm)
Insulation Height 0.339" (8.61mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 8.00µin (0.203µm)
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Keying Slot
Temperature Range - Operating -35°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color White
Voltage Rating 250V
Base Product Number DF1B
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names H3656,*DF1B-18DP-2.5DS(01),-DF1B-18DP-2.5DS(01),541-0636-1-01,*DF1B-18DP-2.5DS(01)-ND
Standard Package 100
Win Source Part Number 1210926-DF1B-18DP-2.5DS(01)
Ultra Librarian 3D Model Ultra Librarian DF1B-18DP-2.5DS(01) CAD Model

Description

The Hirose Electric Co Ltd Rectangular Connector is a high-quality electronic component that comes in a through hole, right angle mounting type.

  • Mounting Type: Through Hole, Right Angle
  • Positions: 18
  • Keying: Keying Slot
  • Voltage Rating: 250V
  • Package: Tray
  • Current Rating (Amps): -
