Same model may have multiple batches, images only for reference.

FH34SRJ-26S-0.5SH(50)

Name: FH34SRJ-26S-0.5SH(50)
Brand: Hirose Electric Co Ltd
SKU: 453838
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FH34SRJ-26S-0.5SH(50)
Manufacturer	Hirose Electric Co Ltd
Catalog	FFC, FPC (FlatFlexible) Connectors
Description	CONN FFC FPC 26POS 0.50MM R/A
Datasheet	FH34SRJ-26S-0.5SH(50) Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Hirose Electric Co Ltd
Packaging	Reel - TR
Status	Active
Flat Flex Type	FFC, FPC
Mounting	Surface Mount, Right Angle
Connector/Contact Type	Contacts, Top and Bottom
Number of Positions	26
Pitch	0.020" (0.50mm)
Termination	Solder
FFC, FCB Thickness	0.30mm
Height Above Board	0.039" (1.00mm)
Locking Feature	Rotary Lock, Backlock
Cable End Type	Tapered
Contact Finish	Gold
Housing Material	Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material	Polyamide (PA), Nylon
Features	Zero Insertion Force (ZIF)
Voltage Rating	50V
Temperature Range - Operating	-55°C to 85°C
Material Flammability Rating	UL94 V-0
Current Rating	0.5A
Housing Color	Gray
Actuator Color	Black
Mating Cycles	20
Win Source Part Number	1038787-FH34SRJ-26S-0.5SH(50)
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	5k pcs
Ultra Librarian 3D Model	Ultra Librarian FH34SRJ-26S-0.5SH(50) CAD Model

Alternative Products

Description

The Hirose Electric Co Ltd FH34SRJ series connector is a 26-position FFC/FPC connector with a pitch of 0.020" (0.50mm).

Positions: 26
Pitch: 0.020" (0.50mm)
Voltage Rating: 50V
Current Rating: 0.5A
Mounting: Surface mount, right angle
Height above Board: 0.039" (1.00mm)
Locking Feature: Rotary lock, backlock
Contact Finish: Gold
Housing Material: Liquid crystal polymer (LCP), halogen free
Material Flammability Rating: UL94 V-0
Housing Color: Gray
Flat Flex Type: FFC, FPC
