FX2CA2-100P-1.27DSAL(71) Hirose Electric Co Ltd
Same model may have multiple batches, images only for reference.

FX2CA2-100P-1.27DSAL(71)

Part No FX2CA2-100P-1.27DSAL(71)
Manufacturer Hirose Electric Co Ltd
Catalog D - SUB, D - SHAPED connectors
Description CONN HDR 100POS 1.27MM
Datasheet
FX2CA2-100P-1.27DSAL(71) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number WS1208068-FX2CA2-100P-1.27DSAL(71)
Manufacturer Hirose Electric Co Ltd
Category Connectors, Interconnects -D-Sub, D-Shaped Connectors- Centronics Connectors
Series FX2
Package Tray
Product Status Active
Connector Style Center Strip Contacts
Connector Type Plug
Mounting Type Through Hole
Type Board to Board
Features Board Lock
Contact Finish Gold
Ultra Librarian 3D Model Ultra Librarian FX2CA2-100P-1.27DSAL(71) CAD Model

Description

  • Flux swell prevention The straight through hole type takes the complete flux tight action from the board back side at solder dipping. The type is prepared, corresponding to whether or not cleaning is required.
  • Stack height 12mm to 16mm The board stack height can be set to every 1 mm unit up to 12 to 16mm.
  • Mis-insertion preventive mechanism The mating area is designed in a mechanism so as to prevent mis-insertion, and complete countermeasures have been taken against wrenching
