Same model may have multiple batches, images only for reference.
SD2440-003 Real Image
Same model may have multiple batches, images only for reference.

SD2440-003

Part No SD2440-003
Manufacturer Honeywell
Catalog Optical Sensors - Phototransistors
Description SENSOR PHOTO TOP VIEW MINI-PILL / Phototransistors Top View Mini-pill
Datasheet
SD2440-003 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Optical Sensors - Phototransistors
Mfr Honeywell Sensing and Productivity Solutions
Package Bulk
Product Status Obsolete
Voltage - Collector Emitter Breakdown (Max) 30 V
Current - Collector (Ic) (Max) 4 mA
Current - Dark (Id) (Max) 100 nA
Viewing Angle 48°
Power - Max 125 mW
Mounting SMD (SMT)
Orientation Top View
Temperature Range - Operating -55°C ~ 125°C (TA)
Package / Case Mini-pill
Other Names 480-1971,SD2440003,480-1971R
Standard Package 100
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.7080
Win Source Part Number 1234925-SD2440-003
Ultra Librarian 3D Model Ultra Librarian SD2440-003 CAD Model

Description

The Honeywell Sensing and Productivity Solutions 1234925-SD2440-003 is an optical sensor designed for phototransistors.

  • Package: 100 sensors in bulk
  • Orientation: Top view
  • Mounting: SMD (SMT)
  • Power Rating: 125mW
  • Voltage Collector Emitter Breakdown (max): 30V
  • Current Collector (Ic) (max): 4mA
  • Viewing Angle: 48°
  • Wavelength: Not specified
  • Current Dark (Id) (max): 100nA
  • Package/Case: Mini-pill
  • Temperature Range for Operating: -55°C to +125°C
  • MSL Level: 1 (unlimited)
  • ECCN: EAR99
