RU4S-D24 Real Image
Same model may have multiple batches, images only for reference.

RU4S-D24

Part No RU4S-D24
Manufacturer IDEC
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE 4PDT 6A 24V / General Purpose Relay 4PDT (4 Form C) 24VDC Coil Socketable
Datasheet
RU4S-D24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr IDEC
Series RU
Package Bulk
Product Status Active
Mounting Type Socketable
Coil Voltage 24VDC
Contact Form 4PDT (4 Form C)
Contact Rating (Current) 6 A
Switching Voltage 250VAC, 30VDC - Max
Coil Current 44.7 mA
Coil Type Non Latching
Features Lighted Indicator, Mechanical Indicator, Test Button
Termination Style Plug In
Must Operate Voltage 19.2 VDC
Must Release Voltage 2.4 VDC
Operate Time 20 ms
Release Time 20 ms
Temperature Range - Operating -55°C ~ 60°C
Contact Material Silver (Ag), Gold (Au)
Relay Type General Purpose
Coil Resistance 605 Ohms
Base Product Number RU4S
Standard Package 1 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.49.0050
California Prop 65 Warning Information
Win Source Part Number 892632-RU4S-D24
Ultra Librarian 3D Model Ultra Librarian RU4S-D24 CAD Model

Description

The 892632-RU4S-D24 is a power relay from the RU series by IDEC.

  • Type: Plug-in Relay
  • Features: Lighted Indicator, Mechanical Indicator, and Test Button
  • Contact Form: 4PDT (4 Form C)
  • Contact Material: Silver (Ag), Gold (Au)
  • Coil Resistance: 605 Ohms
  • Coil Current: 44.7 mA
  • Operate Time: 20 ms
  • Release Time: 20 ms
  • Coil Voltage: 24VDC
  • Contact Rating: 6 A
  • Switching Voltage: Up to 250VAC and 30VDC
  • Operating Temperature Range: -55°C to 60°C
  • Mounting: Socketable
  • Type: General-Purpose Relay
