BSC035N10NS5ATMA1 Real Image BSC035N10NS5ATMA1 Real Image1 BSC035N10NS5ATMA1 Real Image2 BSC035N10NS5ATMA1 Real Image3
Same model may have multiple batches, images only for reference.
BSC035N10NS5ATMA1 Real Image BSC035N10NS5ATMA1 Real Image1 BSC035N10NS5ATMA1 Real Image2 BSC035N10NS5ATMA1 Real Image3
BSC035N10NS5ATMA1 Real Image BSC035N10NS5ATMA1 Real Image1 BSC035N10NS5ATMA1 Real Image2 BSC035N10NS5ATMA1 Real Image3
Same model may have multiple batches, images only for reference.

BSC035N10NS5ATMA1

Part No BSC035N10NS5ATMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 100A TDSON-8
Datasheet
BSC035N10NS5ATMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 3.8V @ 115μA
Max Gate Charge 87nC @ 10V
Max Input Capacitance 6500pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 156W (Tc)
Maximum Rds On at Id,Vgs 3.5 mOhm @ 50A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TDSON-8
Dimension 8-PowerTDFN
Win Source Part Number 1024329-BSC035N10NS5ATMA1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSC035N10NS5ATMA1 CAD Model

Description

The Infineon Technologies BSC035N10NS5ATMA1 is an N-channel MOSFET with a PG-TDSON-8 package and a drain-source breakdown voltage of 100V.

  • Channel Type: N-channel
  • Package: PG-TDSON-8
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 100A (Tc) @ 25°C
  • Maximum Rds On: 3.5 mOhm @ 50A, 10V
  • Drive Voltage: 6V, 10V
  • Gate-Source Threshold Voltage: 3.8V @ 115μA
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Gate Charge: 87nC @ 10V
  • Supply and Demand Status: Limited
