BSC039N06NSATMA1 Infineon Technologies BSC039N06NSATMA1 Real Image1 BSC039N06NSATMA1 Real Image2
Same model may have multiple batches, images only for reference.
BSC039N06NSATMA1 Infineon Technologies BSC039N06NSATMA1 Real Image1 BSC039N06NSATMA1 Real Image2
BSC039N06NSATMA1 Infineon Technologies BSC039N06NSATMA1 Real Image1 BSC039N06NSATMA1 Real Image2
Same model may have multiple batches, images only for reference.

BSC039N06NSATMA1

Part No BSC039N06NSATMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 19A/100A TDSON  /  N-Channel 60 V 19A (Ta), 100A (Tc) 2.5W (Ta), 69W (Tc) Surface Mount PG-TDSON-8-6
Datasheet
BSC039N06NSATMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr Infineon Technologies
Series OptiMOS™
Package Tape & Reel
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V
Current - Continuous Drain (Id) @ 25°C 19A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Rds On (Max) @ Id, Vgs 3.9mOhm @ 50A, 10V
Vgs(th) (Max) @ Id 2.8V @ 36µA
Gate Charge (Qg) (Max) @ Vgs 27 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 2000 pF @ 30 V
Power Dissipation (Max) 2.5W (Ta), 69W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting SMD (SMT)
Supplier Device Package PG-TDSON-8-6
Package / Case 8-PowerTDFN
Base Product Number BSC039
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names BSC039N06NSTR,BSC039N06NSCT-ND,BSC039N06NSDKR,BSC039N06NSATMA1DKR,BSC039N06NSATMA1CT,BSC039N06NSDKR-ND,BSC039N06NS-ND,BSC039N06NSATMA1TR,SP000985386,BSC039N06NSTR-ND,BSC039N06NS
Standard Package 5,000
Win Source Part Number 1049663-BSC039N06NSATMA1
Ultra Librarian 3D Model Ultra Librarian BSC039N06NSATMA1 CAD Model

Description

The Infineon Technologies BSC039N06NSATMA1 is a MOSFET transistor that is used in FETs, MOSFETs - Single applications.

  • Category: Discrete Semiconductor Products
  • Drain to Source Voltage: 60V
  • Continuous Drain Current: 19A (Ta), 100A (Tc)
  • Maximum Rds On: 3.9mOhm @ 50A, 10V
  • Maximum Gate Charge: 27 nC @ 10V
  • Package: 8-PowerTDFN
