Same model may have multiple batches, images only for reference.

BSC066N06NSATMA1

Name: BSC066N06NSATMA1
Brand: Infineon Technologies
SKU: 1324076
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	BSC066N06NSATMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 60V 64A TDSON-8-6 / N-Channel 60 V 64A (Tc) 2.5W (Ta), 46W (Tc) Surface Mount PG-TDSON-8-6
Datasheet	BSC066N06NSATMA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Manufacturer	Infineon Technologies
Packaging	Reel - TR
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60 V
Current - Continuous Drain (Id) @ 25°C	64A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Rds On (Max) @ Id, Vgs	6.6mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	3.3V @ 20µA
Gate Charge (Qg) (Max) @ Vgs	21 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1500 pF @ 30 V
Power Dissipation (Max)	2.5W, 46W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting	Surface Mount
Supplier Device Package	PG-TDSON-8-6
Case / Package	8-PowerTDFN
Base Product Number	BSC066
RoHS Status	ROHS3 Compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Part Number	SP001067000,BSC066N06NSATMA1TR,BSC066N06NSATMA1DKR,BSC066N06NSATMA1-ND,BSC066N06NSATMA1CT
Standard Package	5,000
Win Source Part Number	1324076-BSC066N06NSATMA1
Ultra Librarian 3D Model	Ultra Librarian BSC066N06NSATMA1 CAD Model

Alternative Products

Description

The Infineon Technologies 1324076-BSC066N06NSATMA1 is a discrete semiconductor product that belongs to the transistors - FETs, MOSFETs - single category.

Polarity: N-channel
Drain-Source Breakdown Voltage: 60V
Continuous Drain Current (Id): 64A (Tc) @ 25°C
Rds On (Max) @ Id, Vgs: 6.6mOhm @ 50A, 10V
Vgs(th) (Max) @ Id: 3.3V @ 20μA
Power Dissipation (max): 2.5W, 46W (Tc)
Gate Charge (Qg) (Max) @ Vgs: 21 nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1500 pF @ 30V
Vgs (Max): ±20V
Active: active
