BSP297H6327XTSA1 Infineon Technologies BSP297H6327XTSA1 Real Image1 BSP297H6327XTSA1 Real Image2
Same model may have multiple batches, images only for reference.
BSP297H6327XTSA1 Infineon Technologies BSP297H6327XTSA1 Real Image1 BSP297H6327XTSA1 Real Image2
BSP297H6327XTSA1 Infineon Technologies BSP297H6327XTSA1 Real Image1 BSP297H6327XTSA1 Real Image2
Same model may have multiple batches, images only for reference.

BSP297H6327XTSA1

Part No BSP297H6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 660MA SOT-223
Datasheet
BSP297H6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 660mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1.8V @ 400μA
Max Gate Charge 16.1nC @ 10V
Max Input Capacitance 357pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.8W (Ta)
Maximum Rds On at Id,Vgs 1.8 Ohm @ 660mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SOT223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 136769-BSP297H6327XTSA1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSP297H6327XTSA1 CAD Model

Description

Overview

The BSP297H6327XTSA1 is a high-performance N-channel MOSFET transistor designed to meet the demands of various electronic applications. This component is renowned for its robust construction and efficiency in switching applications.

Features and Benefits

  • Low on-state resistance, enhancing energy efficiency.
  • High-speed switching capabilities, crucial for time-sensitive applications.
  • Compact SOT-223 package, ideal for space-constrained projects.
  • Wide temperature range, suitable for challenging environmental conditions.

Applications

  • Power Management Systems
  • DC-DC Converters
  • Motor Control Circuits
  • Switching Regulators

Additional Details

Operating voltage is standardized for adaptability across different circuits, making the BSP297H6327XTSA1 a versatile choice for both commercial and industrial sectors.
