BSR316PH6327XTSA1 Infineon Technologies BSR316PH6327XTSA1 real image15222
Same model may have multiple batches, images only for reference.
BSR316PH6327XTSA1 Infineon Technologies BSR316PH6327XTSA1 real image15222
BSR316PH6327XTSA1 Infineon Technologies BSR316PH6327XTSA1 real image15222
Same model may have multiple batches, images only for reference.

BSR316PH6327XTSA1

Part No BSR316PH6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 100V 360MA SC-59-3
Datasheet
BSR316PH6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 360mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1V @ 170μA
Max Gate Charge 7nC @ 10V
Max Input Capacitance 165pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 500mW (Tc)
Maximum Rds On at Id,Vgs 1.8 Ohm @ 360mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SC-59
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 1024474-BSR316PH6327XTSA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSR316PH6327XTSA1 CAD Model

Description

The Infineon Technologies MOSFET is a discrete semiconductor product.

  • Supply and Demand Status: balanced
  • Manufacturer: Infineon Technologies
  • Win Source Part Number: 1024474-BSR316PH6327XTSA1
  • Category: MOSFET
  • Polarity: P-Channel
  • Power Dissipation (Max): 500mW (Tc)
  • Drain-Source Breakdown Voltage: 100V
