BSZ036NE2LS

Part No BSZ036NE2LS
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description n-Channel Power MOSFET
Datasheet
BSZ036NE2LS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Series OptiMOS
Packaging Reel - TR
Channel Type Type N
Technology MOSFET
Drain Source Voltage 25V
Current - Continuous Drain (Id) @ 25°C 16A (Ta), 40A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 16nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 1200pF @ 12V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 2.1W (Ta), 37W (Tc)
Rds On (Maximum) @ Id, Vgs 3.6 mOhm @ 20A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package PG-TSDSON-8-FL
Package 8-PowerTDFN
Win Source Part Number 1154997-BSZ036NE2LS
Manufacturer Homepage www.infineon.com
Family Name BSZ036NE2LS
Introduction Date March 21, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2025
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSZ036NE2LS CAD Model

Description

The BSZ036NE2LS is a MOSFET transistor from the OptiMOS series by Infineon Technologies.

  • Continuous drain current: 16A @ 25°C and 40A @ Tc
  • Drive voltage for max Rds On: 4.5V
  • Drive voltage for min Rds On: 10V
  • Drain source voltage: 25V
  • Gate-source threshold voltage: 2V @ a current of 250μA
  • Maximum gate charge: 16nC @ 10V
  • Input capacitance: 1200pF @ 12V
  • Package: 8-PowerTDFN package
  • Operating temperature range: -55°C to 150°C
  • Supply and demand status: balanced
