BSZ042N06NSATMA1

Name: BSZ042N06NSATMA1
Brand: Infineon Technologies
SKU: 770439
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	BSZ042N06NSATMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 60V 19A 8TSDSON / Trans MOSFET N-CH 60V 40A 8-Pin TSDSON EP T/R
Datasheet	BSZ042N06NSATMA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Series	OptiMOS
Packaging	Reel package
Channel Type Type	N
Technology	MOSFET
Drain Source Voltage	60V
Current - Continuous Drain (Id) @ 25°C	17A (Ta), 40A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Vgs(th) (Maximum) @ Id	2.8V @ 36μA
Gate Charge (Qg) (Maximum) @ Vgs	27nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	2000pF @ 30V
Vgs (Maximum)	±20V
Power Dissipation (Maximum)	2.1W (Ta), 69W (Tc)
Rds On (Maximum) @ Id, Vgs	4.2 mOhm @ 20A, 10V
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting	SMD
Manufacturer Package	PG-TSDSON-8-FL
Package	8-PowerTDFN
Win Source Part Number	770439-BSZ042N06NSATMA1
Popularity	Medium
Supply and Demand Status	Balance
Family Name	BSZ042N06NS
Introduction Date	December 02, 2011
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian BSZ042N06NSATMA1 CAD Model

Alternative Products

Description

The 770439-BSZ042N06NSATMA1 from Infineon Technologies is a MOSFET transistor.

Continuous Drain (Ta): 17A
Continuous Drain (Tc): 40A
Drive Voltage: 6V, 10V
Drain-Source Voltage: 60V
Gate-Source Threshold Voltage: 2.8V @ 36μA
Package: PG-TSDSON-8-FL
Power Dissipation (Ta): 2.1W
Power Dissipation (Tc): 69W
Maximum Input Capacitance: 2000pF @ 30V
Maximum Gate Charge: 27nC @ 10V
Series: OptiMOS
Popularity: Medium
Supply and Demand Status: Balanced
