IPD110N12N3GATMA1 Real Image IPD110N12N3GATMA1 real image10296
Same model may have multiple batches, images only for reference.
IPD110N12N3GATMA1 Real Image IPD110N12N3GATMA1 real image10296
IPD110N12N3GATMA1 Real Image IPD110N12N3GATMA1 real image10296
Same model may have multiple batches, images only for reference.

IPD110N12N3GATMA1

Part No IPD110N12N3GATMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 120V 75A TO252-3
Datasheet
IPD110N12N3GATMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 120V
Continuous Drain Current at 25°C 75A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 3V @ 83μA (Typ)
Max Gate Charge 65nC @ 10V
Max Input Capacitance 4310pF @ 60V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 136W (Tc)
Maximum Rds On at Id,Vgs 11 mOhm @ 75A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TO252-3
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1045852-IPD110N12N3GATMA1
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IPD110N12N3GATMA1 CAD Model

Description

The Infineon Technologies IPD110N12N3GATMA1 is a high-performance N-Channel MOSFET designed for use in various electronic circuits.

  • Drain-Source Breakdown Voltage: 120V
  • Continuous Drain Current (25°C): 75A @ 25°C
  • Gate-Source Threshold Voltage: 3V @ 83μA
  • Maximum Gate Charge: 65nC @ 10V
  • Maximum Input Capacitance: 4310pF @ 60V
  • Maximum Rds On (Id, Vgs): 11 mOhm @ 75A, 10V
  • Case/Package: PG-TO252-3
  • Mounting Type: SMD (SMT)
