Same model may have multiple batches, images only for reference.

IPD60R600P6

Name: IPD60R600P6
Brand: Infineon Technologies
SKU: 158412
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IPD60R600P6
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 600V 7.3A 3-Pin(2+Tab) DPAK T/R / MOSFET N-CH 600V 7.3A TO252
Datasheet	IPD60R600P6 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	600V
Continuous Drain Current at 25°C	7.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4.5V @ 200μA
Max Gate Charge	12nC @ 10V
Max Input Capacitance	557pF @ 100V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	63W (Tc)
Maximum Rds On at Id,Vgs	600 mOhm @ 2.4A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	PG-TO252-3
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	040635-IPD60R600P6
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	IPD60R600P6
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2029
Ultra Librarian 3D Model	Ultra Librarian IPD60R600P6 CAD Model

Alternative Products

Description

The Infineon Technologies 040635-IPD60R600P6 is a high-performance N-channel MOSFET designed for use in discrete semiconductor products.

Drain-Source Breakdown Voltage: 600V
Continuous Drain Current: 7.3A @ 25°C
Mounting: SMD (SMT)
Package: Reel
Power Dissipation: 63W (Tc)
Gate-Source Threshold Voltage: 4.5V @ 200μA
Maximum Gate Charge: 12nC @ 10V
Maximum Input Capacitance: 557pF @ 100V
Compliance: Halogen-free standards
Manufactured In: Malaysia
Estimated EOL Date: 2029
Popularity: High popularity
