Same model may have multiple batches, images only for reference.

IPP50CN10NG

Name: IPP50CN10NG
Brand: Infineon Technologies
SKU: 158606
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IPP50CN10NG
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 100V 20A 3-Pin(3+Tab) TO-220 / MOSFET N-CH 100V 20A TO-220
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Obsolete(EOL)
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	100V
Continuous Drain Current at 25°C	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 20μA
Max Gate Charge	16nC @ 10V
Max Input Capacitance	1090pF @ 50V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	44W (Tc)
Maximum Rds On at Id,Vgs	50 mOhm @ 20A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	PG-TO-220-3
Dimension	TO-220-3
Win Source Part Number	069064-IPP50CN10NG
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IPP50CN10N
Introduction Date	February 17, 2006
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian IPP50CN10NG CAD Model

Alternative Products

Description

The Infineon Technologies IPP50CN10NG is an N-channel MOSFET transistor that is designed to provide high power dissipation capabilities.

Maximum Power Dissipation: 44W
Maximum Continuous Drain Current: 20A
Voltage Breakdown: 100V
Gate-Source Threshold Voltage: 4V @ 20μA
Maximum Input Capacitance: 1090pF @ 50V
Mounting: Through-hole
Operating Temperature Range: -55°C to 175°C
Package: PG-TO-220-3
Halogen-Free Compliance: Yes
Family: IPP50CN10N
Category: Discrete semiconductor products
Status: Obsolete
EOL Date: Estimated
Alternative Parts: 2SK3149-E, STP24NF10, and STP25N10F7
