IR2106STRPBF

Name: IR2106STRPBF
Brand: Infineon Technologies
SKU: 158833
Availability: InStock
Rating: 4.85 (489 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR2106STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HIGH/LOW SIDE 8SOIC
Datasheet	IR2106STRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 2.9V
Current - Peak Output (Source, Sink)	200mA, 350mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	150ns, 50ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	017349-IR2106STRPBF
Family Name	IR2106
Introduction Date	January 10, 2003
ECCN	EAR99
Country of Origin	Malaysia, Thailand
Halogen Free	Not Compliant
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IR2106STRPBF CAD Model

Description

The IR2106STRPBF from Infineon Technologies is an active integrated circuit that is used in industrial, consumer electronics, alternative energy, and power management applications.

Configuration: half-bridge driven
Channels: two independent
Input Type: non-inverting
Gate Type: IGBT and N-Channel MOSFET
Logic Voltage: VIL=0.8V and VIH=2.9V
Current Peak Output: 200mA and 350mA
High Side Voltage: 600V (max)
Rise Time: 150ns
Fall Time: 50ns
Packaging: reel-TR
Mounting: SMD(SMT)
